| Part Number | Description | Related Products |
|---|---|---|
| CPS4041 | The CPS4041 is a highly efficient, Qi-compliant, single-chip Wireless Power Receiver/Transmitter IC. It supports up-to 60W （max 3A）capability under receiver (Rx) mode and up-to 20W capability undertransmitter (Tx) mode, which is particularly suitable for cell phone and portable device applications. | Wireless Charger > Wireless Charger Receiver |
| CPS4059 | Wireless Charger > Wireless Charger Receiver | |
| CPS4061 | The CPS4061 is a highly efficient, Qi-compliant, single-chip wireless power receiver and transmitter. It supports up to 100W applications at receiver (Rx) mode, which is particularly suitable for phone and portable device applications. | Wireless Charger > Wireless Charger Receiver |
| CPS4052 | Wireless Charger > Wireless Charger Receiver | |
| CPS4021 | The CPS4021 is a highly efficient, Qi-compliant,single-chip wireless power receiver/transmitter lC. lt supports up-to 30W capability at receiver (Rx)modeand up-to 10w capability at transmitter(Tx) mode.which is particularly suitable for cell phone and portable device applications. | Wireless Charger > Wireless Charger Receiver |
| Part Number | Description | Related Products |
|---|---|---|
| CPS8851 | The CPS8851 is an USB Type-C controller with Power delivery that complies with the physical layer and implements the Type-C port power control for VCONN, Type-C CC control, sensing and PD message delivery. | Protocols > Sink and DRP |
| CPS8853 | The CPS8853 is a USB A controller that complies with UFCS standard. The CPS8853 integrates a complete DP/DM PHY which supports the customized fast-charging protocol for power input. | Protocols > Sink and DRP |
| Part Number | Description | Related Products |
|---|---|---|
| CPS5389 | The CPS5389 is a fully-integrated synchronous boost converter. The device provides a small and efficient power solution for portable equipment. The CPS5389 features wide input voltage range from 2.7V to 12V to support applications powered with single cell or two cell Lithium ion or polymer batteries. The CPS5389 supports 7A continuous switch current and provides output voltage up to 12.6V | Analog Power > DC/DC |
| Part Number | Description | Related Products |
|---|---|---|
| CPS2020 | CPS2020 is a high efficiency charge pump solution. It supports up to 24V input voltage, and can operate in forward 2:1 charge-pump(max 6A output), reverse 1:2 charge pump, forward or reserve bypass mode. The charge pump structure only needs ceramic capacitors and no inductance is required, which effectively saves solution size. It also supports parallel operation with SYNC pin | Charger > Switched-Cap Charger |
| CPS2011 | CPS2011 is a single-cell 7A high efficiency dualphase switched capacitor charger. It integrated Universal Fast Charging Specification for Mobile Devices (UFCS PHY). It supports up to 12V input voltage, and operates in following 2 modes: Forward 2:1 (up to 7A IOUT), Forward 1:1 (bypass, up to 5A IOUT) The switched capacitor architecture optimized for 50% duty cycle. The input Voltage is 2x of battery voltage and the output current is 2x of VBUS input current, which effectively reduces power loss across the input cable. | Charger > Switched-Cap Charger |
| CPS2011S | CPS2011S is a single-cell 8A high efficiency dual-phase switched capacitor charger. It integrated Universal Fast Charging Specification for Mobile Devices (UFCS PHY). It supports up to 12V input voltage, and operates in following 2 modes: Forward 2:1 (up to 8A IOUT) , Forward 1:1 (bypass, up to 5A IOUT). The switched capacitor architecture optimized for 50% duty cycle. The input Voltage is 2x of battery voltage and the output current is 2x of VBUS input current, which effectively reduces power loss across the input cable. CPS2011S integrates protection schemes including input/output over-voltage/current protection, and over temperature protection. It has built-in I2C slave interface for Application Processor configurations. | Charger > Switched-Cap Charger |
| CPS2023 | CPS2023 is a 97.4% peak efficiency, 13.6-A batterycharging solution using dualphase 4:1 switchedcapacitor architecture for single cell Li-ion battery. | Charger > Switched-Cap Charger |
| Part Number | Description | Related Products |
|---|---|---|
| CPS5601 | CPS5601 is a highly integrated 3A switching mode buck charger with NVDC power path management for single cell Li-ion and Li-polymer battery. Its input voltage and input current regulation deliver maximum charging power to the battery. The compact solution integrates the input reverse-blocking FET (RBFET, Q1), high-side switching FET (HSFET, Q2), low-side switching FET (LSFET, Q3), and battery FET (BATFET, Q4) between system and battery. It also integrates the bootstrap diode for the high-side gate driver to simplify the system design. The I2C serial interface with fully charging and system settings makes the device a truly flexible solution. The device comes in a 24-pin, 4mm × 4mm QFN package. | Charger > Switching/Linear Charger |
| Part Number | Description | Related Products |
|---|---|---|
| CPS5054A | Analog Power > LDO | |
| CPS5057B | Analog Power > LDO |
| Part Number | Description | Related Products |
|---|---|---|
| CPS5080 | The CPS5080 is an ultra-efficient load switch with ultra-low quiescent current of typical 65nA. CPS5080 operates with input voltage range from 1.0V to 5.5V. It is able to deliver up 2A output current. The CPS5080 provides ultra-low quiescent current IQ and shutdown current ISD. With reduced leakage current, overall system power efficiency and operation life are improved. | Analog Power > Load Switch and OVP |
| Part Number | Description | Related Products |
|---|---|---|
| CPS5541 | CPS5541 is a high performance, double pole double throw (DPDT) CMOS analog switch that operates from a single +2.3V to +5.5V power supply. CPS5541 is designed for switching of high-speed USB2.0 signals in handset and consumer applications, such as cell phones, digital cameras, and notebooks with hubs or controllers with limited USB I/Os. | Analog Power > Analog Switch |
| Part Number | Description | Related Products |
|---|---|---|
| CPS2401 | The CPS2401 is a level translator between SIM card and advance low logic level processor or microcontroller with ISO/IEC 7816-3 compliant interface specification. | Analog Power > Level Shifter |
| CPS2401 | The CPS2401 is a level translator between SIM card and advance low logic level processor or microcontroller with ISO/IEC 7816-3 compliant interface specification. | Analog Power > Level Shifter |
