Index Applications Consumer Electronics

Wireless Power Tx
Part Number Description Related Products
CPS8601 CPS8601 is a highly efficient, Qi-compliant, magneticinductive wireless power transmitter lC with wideinput voltage range of 3.3V to 14V. lt supports securecommunication with wireless power receiver (ASK)fixed communication interface ports, as well asreliable over-voltage/current/temperature protectionschemes Wireless Charger > Wireless Charger Transmitter
CPS8610 CPS8610 is a highly efficient, Qi-compliant, magnetic inductive wireless power transmitter lC with wide input voltage range of 3.3V to 24V for VIN, 3.3V to22V for PVlN.lt integrates one 32bit MCU coreflexible adaptor interface, secure communication with wireless power receiver(ASK de-modulator &FSK modulator), one full bridge and EMl-friendly drivers PWM modules with FSK PHY Wireless Charger > Wireless Charger Transmitter
CPS8200 CPS8200 is a highly efficient, Qi-compliant, magnetic inductive Wireless Power Transmitter IC with wide voltage range of 3.9V to 24V (26V max) for VIN, 2V to 45V (50V max) for power stage. It supports secure Bi-directional communication with Wireless Power Receiver (ASK/FSK), flexible communication interface ports, as well as reliable Over-Voltage/Current/Temperature Protection schemes. Wireless Charger > Wireless Charger Transmitter
Wireless Power Rx
Part Number Description Related Products
CPS4019 The CPS4019 is a highly efficient, Qi-compliant, single-chip Wireless Power Receiver IC. It supports up to 5W applications in the Receiver (Rx) Mode. The device receives AC power from a Wireless Power Transmitter (Tx) and converts it into a rectified output voltage. As a Rx, it integrates a synchronous rectifier and a low drop-out regulator to provide power to system load or battery. Modulation and control circuits are used for bi-directional in-band communication to the Tx. Wireless Charger > Wireless Charger Receiver
DRP Controller
Part Number Description Related Products
CPS8853 The CPS8853 is a USB A controller that complies with UFCS standard. The CPS8853 integrates a complete DP/DM PHY which supports the customized fast-charging protocol for power input. Protocols > Sink and DRP
Buck
Part Number Description Related Products
CPS5333 The CPS5333 is a high efficiency, 750 kHz switch frequency, synchronous step-down DC-DC converter with delivering 3A current capability. The CPS5333 operates over a wide input voltage range from 4.5V to 30V and integrates main switch and synchronous switch with very low RDS(ON) to minimize the conduction loss Analog Power > DC/DC
;
