Index Applications Accessories

Wireless Power Tx
Part Number Description Related Products
CPS8600 CPS8600 is a highly efficient, Qi-compliant, magnetic inductive Wireless Power Transmitter IC with wide input voltage range of 3.3V to 24V for VIN, 2V to 14V for power stage. It supports Secure Communication with Wireless Power Receiver (ASK), fixed communication interface ports, as well as reliable Over-Voltage/Current/Temperature Protection schemes. Wireless Charger > Wireless Charger Transmitter
CPS8601 CPS8601 is a highly efficient, Qi-compliant, magneticinductive wireless power transmitter lC with wideinput voltage range of 3.3V to 14V. lt supports securecommunication with wireless power receiver (ASK)fixed communication interface ports, as well asreliable over-voltage/current/temperature protectionschemes Wireless Charger > Wireless Charger Transmitter
CPS8602 CPS8602 is a highly efficient, Qi-compliant, magnetic inductive wireless power transmitter lc with wide input voltage range of 3.3V to 14V. lt supports secure communication with wireless power receiver (ASK)fixed communication interface ports, as well as reliable over-voltage/current/temperature protection schemes. Wireless Charger > Wireless Charger Transmitter
CPS8610 CPS8610 is a highly efficient, Qi-compliant, magnetic inductive wireless power transmitter lC with wide input voltage range of 3.3V to 24V for VIN, 3.3V to22V for PVlN.lt integrates one 32bit MCU coreflexible adaptor interface, secure communication with wireless power receiver(ASK de-modulator &FSK modulator), one full bridge and EMl-friendly drivers PWM modules with FSK PHY Wireless Charger > Wireless Charger Transmitter
CPS8100 CPS8100 is a highly efficient, Qi-compliant, magnetic inductive wireless power transmitter IC with wide input voltage range of 3.9V to 26V. lt supports secure bi-directional communication with wireless power receiver (ASK/FSK), flexible communication interface ports, as well as reliable over-voltage/current)temperature protection schemes Wireless Charger > Wireless Charger Transmitter
CPS8200 CPS8200 is a highly efficient, Qi-compliant, magnetic inductive Wireless Power Transmitter IC with wide voltage range of 3.9V to 24V (26V max) for VIN, 2V to 45V (50V max) for power stage. It supports secure Bi-directional communication with Wireless Power Receiver (ASK/FSK), flexible communication interface ports, as well as reliable Over-Voltage/Current/Temperature Protection schemes. Wireless Charger > Wireless Charger Transmitter
Buck
Part Number Description Related Products
CPS5333 The CPS5333 is a high efficiency, 750 kHz switch frequency, synchronous step-down DC-DC converter with delivering 3A current capability. The CPS5333 operates over a wide input voltage range from 4.5V to 30V and integrates main switch and synchronous switch with very low RDS(ON) to minimize the conduction loss Analog Power > DC/DC
;
