| Part Number | Description | Related Products |
|---|---|---|
| CPSQ5206(AEC-Q100) | CPSQ5206 is an AEC-Q100 qualified, synchronous 4-switch buck-boost controller capable of providing a regulated output voltage which is below, above or exactly equal to the input voltage. Based on different input voltage and output voltage combinations, the converter is operated in either buck, boost or buckboost mode. The converter achieves dynamic and seamless transition among different operating modes without host control. | Automotive > Auto DCDC |
| Part Number | Description | Related Products |
|---|---|---|
| CPSQ8830 | The CPsQ8830 is a highly integrated 36V, 3A step down converter with multiple USB fast charging protocol. it can supply wide input voltage range from 5.5V to 36V and wide output voltage range from 3.3V to 21V with maximum 27W output power. | Automotive > Auto Fast Charging Protocol |
| CPSQ8831 | The CPSQ8831 is a highly integrated 3A, 36V step-down converter with multiply USB fast charging protocol. It can supply wide input voltage range from 5.5V to 36V and wide output voltage range from 3.3V to 21V with 3A output current. | Automotive > Auto Fast Charging Protocol |
| Part Number | Description | Related Products |
|---|---|---|
| CPSQ8841H/CPSQ8841M | CPSQ8841H/M is a highly integrated fast charge protocol source controller that supports many charging protocols | Automotive > Auto Fast Charging Protocol |
| CPSQ8849A | Automotive Type-C Source controller, PD3.0/PD3.1/QC/PPS/FCP/SCP | Automotive > Auto Fast Charging Protocol |
| CPSQ8860/CPSQ8860H | CPSQ8860 is a highly integrated dual-port charging chip for source controller with dual-port that supports multiple fast charge protocols | Automotive > Auto Fast Charging Protocol |
