ConvenientPower Accessories power management application designs help to build better power solutions.
Wireless Power
Part Number Description Related Products
CPS8500 CPS8500 is a highly efficient, Qi-compliant, inductive wireless power transmitter IC with wide input voltage range of 4.5V to 12V. It offers a fully integrated solution that includes a full-bridge power stage, communication blocks with multi-channel demodulation, voltage / current sensing for foreign object detection (FOD), as defined in Wireless Power Consortium (WPC) Qi standard. It also supports reliable over-voltage / over-current / over-temperature protection schemes. Wireless Charging > Wireless Power Transmitter
CPS4047 The CPS4047 is a highly efficient, Qi-compliant, single-chip wireless power receiver/transmitter IC. It supports up-to 40W applications at receiver (Rx) mode and up-to 10W at transmitter (Tx) mode, which is particularly suitable for cell phone and portable device applications. Wireless Charging > Wireless Power Receiver
Protocol
Part Number Description Related Products
CPS8852 CPS8852 is a highly integrated USB Power Delivery 3.0 DRP controller IC. It also supports other DP/DM based charging protocols as BC1.2, QC2.0, QC3.0+,etc. CPS8852 can update the firmware via I2C and CC lines. USB Type-C and PD Protocols > Sink and DRP
